ED/DF150 22” CCM322/522 Nordic Style Lid Kit Installation Instructions
© 2007, IMI Cornelius Inc. - 1 - Publication Number: 620204723INS
INSTALLATION INSTRUCTIONS
ED/DF150 22” CCM322/522 NORDIC BLACK/GRAY STYLE LID KITS
This Nordic style kit applies to the Cornelius 22” wide CCM322/522 ice maker.
CAUTION: Disconnect electrical power to the dispenser before proceeding with the icemaker
adapter kit installation.
WARNING: The dispenser must be secured with 3/8-16 bolts (6) to the counter before installing
this Icemaker Adapter Kit. Refer to the installation manual and Figure 2 for the counter mounting
template.
WARNING:
1. Unpack kit.
2. Place insulation strip (item 12) over studs on the baffle and insert baffle assembly into the adapter
lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item 11), then fasten in place
with (2) plastic acorn nuts (item 8).
4. Set ice maker lid on the top of the dispenser.
5. Using the slotted holes in the lid as a template, drill four (4) .140” diameter (9/64”) holes at the
bottom of the slots (see detail A). Use extreme care not to drill into the hopper. Fasten the lid to the
dispenser with four (4) #8 sheet metal screws, two on each side.
6. Seal the icemaker to the top of the dispenser as follows:
A. Run beads of RTV around the opening in the lid and inside of the perimeter of the ice maker
outline so that the icemaker will set on the RTV.
B. Set the icemaker onto the lid and position it as required.
C. Wipe away the excess RTV.
7. Drill 9/64_ diameter holes into the icemaker cabinet using the bracket as a template. Use extreme
care not to drill into any icemaker components (condenser, tubing, etc.). Secure the brackets using
the screws provided.
8. Install the wire form bracket, supplied with the bin stat kit (item 4), through the 5/8” diameter hole in
the bottom of the ice maker. Wrap the eye of the wireform over the stud near the hole to the end of
the wireform bracket and wrap the tube around the end of the bracket several times, insuring the
tube is secure.
Item
No.
Part No. Name Qty.
1 52994 Cover, Gray - 08008 1
52934 Cover, Black - 02390 1
2 15506 Lid Assembly 1
3 29565 Bracket 2
4 70217 #8 Screw 6
5 50904 RTV 1
6 90221 Label 1
7 620204723INS Installation Instruction 1
8 620701902 Acorn Nut, 8-32 Nylon 2
9 620701901 Sealing Washer 2
10 620042928 Baffle, Ice DF/ED150 1
11 620701903 #8 Nylon Washer 2
12 620505804 Insulation Strip 1
13 630500109 Bin Stat 1
Release Date: October 5, 2007 www.cornelius.com Revision: A
