ED/DF150 22” CCM322/522 Nordic Style Lid Kit Installation Instructions
© 2007, IMI Cornelius Inc. - 3 - Publication Number: 620204723INS
FIGURE 2. ED/DF150 Kit
(6) PLCS.
VIEW ”A”
(2) PLCS.
SEAL ICE MAKER TO
ITEM (2) WITH RTV
ITEM (5)
ICEMAKER
DRILL 9/64 (.140) DIA.
HOLES USING BOTTOM OF
SLOTTED HOLES AS
A TEMPLA TE.
VIEW ”A”
ENLARGED
1
2
3
4
4
6
