NUMBER OF WIRES
. . . . . . . . . . .
3
MAX. FUSE SIZE
. . . . . . . . . . . . . .
15
SHIPPING WEIGHT LBS (KGS.)
. .
160 (73)
AGENCY LISTINGS
. . . . . . . . . . . .
OPERATING LIMITS
Ambient Temp. Range Air & Water
50° - 110°F (10° - 43°C)
Water Temp. Range
40° - 100°F (4.5° - 38°C)
Water Pressure Ice Maker Water in
Min. 20 psi (1.4 bar)
Max. 60 psi (6.9 bar)
Condenser Inlet Water
(Water cooled only)
Min. 20 psi (1.4 bar)
Max. 60 psi (6.9 bar)
MODEL NO.
Cond.
Unit
Ice Prod.
per 24 hrs.
at 70° Air /
50° Water
lbs. (Kgs.)
Ice Prod.
per 24 hrs.
at 90° Air /
70° Water
lbs. (Kgs.)
Water Used-Gals. (Ltrs.)
per 100 lbs. of ice 90°
Air / 70° Water
Kilowatts
Used per
100 lbs.
of ice 90°
Air / 70°
Water
Heat
Rejection
(Btuh)
Electrical
Rating
Min.
Circuit
Amp.
Ice Prod.
Use
Cond. Use
CCU0220A*1
Air
238 (108)
175 (80)
30.3 (115)
n/a
8.8
4609
115/60/1
11.9
CCU0220W*1
Water
251 (114)
205 (93)
34 (129)
204 (775)
6.4
4463
115/60/1
8.9
CCU0220A*2
Air
241 (110)
168 (76)
30.6 (116)
n/a
8.5
4321
208-
230/60/1
6
CCU0220A*2
Water
232 (105)
192 (87)
36.3 (137)
166.9 (632)
6.6
4263
208-
230/60/1
4.4
CCU0220AF5
Air
211 (96)
143 (65)
32.7 (124)
n/a
8.8
3774
230/50/1
4.9
CCU0220WF5
Water
210 (95)
174 (79)
36.6 (139)
156.3 (592)
6.3
3780
230/50/1
4.1
* Represents cube size. For full cube substitute an “F”, for half cube substitute an “H”.
Please note: air-cooled units require 6” (152 mm) clearance for air intake and exhaust.
1. Application bin storage is 100 lbs. (45 Kgs.) = 90% of Internal Volume x 34 lbs. per cubic foot
2. ARI bin storage is 74 lbs. (34 Kgs.) = 80% of Internal Volume x 30 lbs. per cubic foot
Cube Size:
Width
Depth
Heigth
Full
7/8" (22mm)
7/8" (22mm)
7/8" (22mm)
Half
3/8" (10mm)
7/8" (22mm)
7/8" (22mm)
