Cornelius IMD300-30 Ice Maker User Manual



IMI CORNELIUS INC.
Telephone 1-800-238-3600
www.cornelius.com
ILLUSTRATED PARTS LIST
Manual Part No.: 638085277IPL 14 of 28 IMD Series
Rev: B January 26, 2009
© IMI Cornelius Inc., 2004-2009
ICE CONTROL LEVEL ASSEMBLY IMD 300-30 AND IMD 600-30
* Not Shown
Item
No.
Part No. Name
Item
No.
Part No. Name
1 638031075 Top Cover Outside 14 638031147 Ice Level Plate
2
638031493-001
638031493-002
Dispense Motor Asm. (115V)
Dispense Motor Asm. (220V)
15 638031100-06 Rivnut Fastener
3 638031077 Switch Mounting Bracket 16 638031076 Top Cover Inside
4 638031011 Switch Bracket 17 638007264-02 Nut Tinnerman Twin
5 638031156 Ice Level Switch 18 638031078 Agitator Arm
6 638011396 Bin Control Cable 19 27103 Screw 1/4-20 X 1/2” Long
7 638007308-01 Washer Fibre 20 638007002-03 Screw No.6-32 X 3/8” Long
8 638007009-10 Screw No.6-32 X 1-1/4” Long 21 07313 Strain Relief
9 638031010 Rod Actuator 22 70910 Screw No.10-32 X 1-1/4” Long
10 638031014 Spring Return 23 638007301-18 Washer
11 638007337-02 E-Ring 24 07051-07 Screw No.10-32 X 3/8” Long
12 638031146 Motor Mounting Bracket 25 638031159 Upper Agitator Arm
13 638031150 Diaphram * 638011620 Main Power Cable
