6620913501
STORAGE
HOPPER
GATE
MOUNTING
PLATE
ICE DIVERTER
P/N 15484
ICE CHUTE
FLANGE EXTENDS
INTO STORAGE
HOPPER THROUGH
GATE OPENING
APPLY RTV TO THIS
SURFACE TO SEAL TO
HOPPER GATE
MOUNTING PLATE
GASKET
FLAT WASHER
10--32 NUT
FIGURE 4.
