620909401
March 1998
R
e
v
B
Revised: September 8, 1998
IMI CORNELIUS INC g One Cornelius Place g Anoka, MN 55303-6234
Telephone (800) 238-3600 Facsimile (612) 422-3246
ED150 “K” STYLE LID KITS,
P/N 629083204 AND 629083202
These “K” style kits apply to the following ice maker:
Ice Maker Width
Manitowoc Q320/420 22I
Table 1. Loose-Shipped Parts
Item
No. Part No. Name Qty.
1
52994 Cover, Gray (629083202) 1
1
52934 Cover, Black (629083204)
2 620027505 DF150 Ice Maker Lid Assembly 1
3 620027306 Bracket 2
4 70217 #8 Screw 6
5 50904 RTV 1
6 90221 Label 1
7 620909401 Installation Instruction 1
8 620701902 Acorn Nut, 8--32 Nylon 2
9 620701901 Sealing Washer 2
10 620037007 Baffle, Ice DF/ED150 1
11 621701903 #8 Nylon Washer 2
1. Unpack kit.
2. Insert a baffle assembly into the adapter lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item11), then fasten in place with (2)
plastic acorn nuts (item 8).
4. Set ice maker lid on the top of the dispenser.
5. Using the slotted holes in the lid as a template, drill four (4) 9/64I diameter holes at the bottom of the slots
(see detail A). Use extreme care not to drill into the hopper. Fasten the lid to the dispenser with four (4) #8
sheet metal screws, two on each side.
6. Seal the ice maker to the top of the dispenser as follows:
A. Run beads of RTV around the opening in the lid and inside of the perimeter of the ice maker outline so
that the ice maker will set on the RTV.
