KitchenAid 8304531A Oven User Manual



10
7. Once in the Bake cycle, a Sabbath Mode key will appear in
the lower right hand corner of the display.
8. Touch SABBATH MODE. (If Sabbath Mode does not appear
in the Bake cycle, refer to the “To Enable” section.)
9. Once in the Sabbath Mode, an End Sabbath key will appear
in the lower right hand section of the display. Touch and hold
the End Sabbath Mode for approximately 3 seconds to return
to the regular Bake mode.
10. Once Cook Time has reached 0:00, the Sabbath Mode
Complete message is displayed. The completed time
information is updated every minute but no End of Cycle
tone will sound.
11. Touching the End Sabbath key for approximately 3 seconds
exits the Sabbath Mode and returns to the Main Menu.
12. Touch Upper Oven OFF, Lower Oven OFF or OFF at anytime
to turn the oven off.
To Set Delayed:
Sabbath Mode must be enabled before starting the Bake cycle.
See the “To Enable” section.
1. From the Main menu, touch BAKE.
2. Touch DELAY COOK.
3. Touch BAKE.
4. To change the preset temperature, enter the desired
temperature using the numerical keys. The temperature can
be set between 170°F and 500°F (77°C and 260°C).
5. Touch COOK TIME. Enter the desired cook time using the
numerical keys.
6. Touch DELAY TIME. Enter the amount of time you wish to
delay the start of cooking using the numerical keys.
7. Once a cooking setup function is complete, the Start key will
light up.
8. When settings are correct, touch the Start key.
9. A Sabbath Mode key will appear in the lower right hand
corner of the display.
10. Touch SABBATH MODE. (If Sabbath Mode does not appear
in the Bake cycle, refer to the “To Enable” section.
11. Once the delay time is reached, if the oven temperature is
below the set temperature, the Preheat Bar will be displayed
showing the status of the preheat cycle. When preheat is
complete a tone will sound.
12. Once in the Sabbath Mode, an End Sabbath key will appear
in the lower right hand section of the display. Touch and hold
the End Sabbath Mode for approximately 3 seconds to return
to the regular Bake mode.
13. Once Cook Time has reached 0:00, the Sabbath Mode
Complete message is displayed. The completed time
information is updated every minute but no End of Cycle tone
will sound.
14. Touching the End Sabbath key for approximately 3 seconds
exits the Sabbath Mode and returns to the Main Menu.
15. Touch Upper Oven OFF, Lower Oven OFF or OFF at anytime
to turn the oven off.
Temperature Change
The oven temperature can be changed when the oven(s) are in
the Sabbath Mode. No tones will sound, and the display will not
change. The heating elements will not turn on or off for a random
time, anywhere from 16 to 24 seconds. It may take up to one-half
hour for the oven to change temperature.
Number keys 1 through 0 represent temperatures.
Use the following chart as a guide.
To Change Temperature:
On double oven models, both oven cavities can be set for
independent temperatures. However, once Sabbath Mode is
running, if the temperature is changed both cavities will use the
new temperature.
1. Touch the number key from the chart.
2. Touch START.
Languages
To Change Language Setting:
1. From the Main menu, touch MORE.
2. Touch SETTINGS.
3. Touch LANGUAGES.
4. Touch ENGLISH or FRANÇAIS (French).
5. Touch OK.
Clock
This is a 12-hour clock. Before setting, make sure the oven(s),
Timer and Timed Cooking are off.
To Set:
1. Touch CLOCK SET/START.
2. Enter the desired time by touching the numerical keys to set
the time of day.
3. Touch AM or PM.
4. Touch OK.
5. To turn the clock display off, touch CLOCK SET/START.
6. Touch ON DISPLAY or OFF DISPLAY.
7. Touch OK.
NUMBER KEY OVEN TEMPERATURE
1 170°F (77°C)
2 200°F (95°C)
3 225°F (107°C)
4 250°F (120°C)
5 300°F (149°C)
6 325°F (163°C)
7 350°F (177°C)
8 375°F (191°C)
9 400°F (204°C)
0 450°F (232°C)
