PARTS AND FEATURES
This manual may cover several different models. The model you have purchased may have some or all of the features shown here. The
appearance of your particular model may differ slightly from the illustrations in this manual.
Tu rn t ab le
The turntable can rotate in either direction to help cook food
more evenly. Do not operate the microwave oven without having
the turntable in place. See “Assistance or Service” to reorder any
of the parts.
To Install: The support and hub are preassembled and installed
in the microwave oven. Place the turntable on the support. Fit the
raised, curved lines in the center of the turntable bottom between
the three spokes of the hub. The rollers on the support should fit
inside the turntable bottom ridge.
MICROWAVE OVEN CONTROL
A.Trim
B.Control panel
C.Door safety lock system
D.Model and serial number plate
E.Glass turntable
F. Turntable support, rollers and
hub
G.Door handle
H.Metal shielded window
I.Cooking guide label
J.Frame
K.Microwave oven light
(inaccessible -- in ceiling)
L.Microwave inlet cover
A B C
I H G
J
K
L
D
E
F
A.Turntable
B.Support
C.Hub
A
B
C
A. Dial
A
