FREEZER DOOR AND BASKET PARTS
14
For Model: KBFO42FTX02
(Etched Aluminum)
W10178091
Illus. Part
No. No. DESCRIPTION
1 2327400 Freezer Door
(Includes #9)
2 2317101 Divider,
Basket (2)
3 2314024 Mat, Basket
4
W10135775
Screw, 5/16 x 3/4
5
W10135792
Screw, 8/32 x 1/4
6
W10109030
Screw
7 2313999S Trim−Door, Side
8 2313998S Trim−Door,
Top & Bottom
9 2309216 Door Gasket,
Magnetic
10 2309033S Cover−Trim, Top
11 2309213S Cover−Trim, Side
13 8281250 Screw, 8−15 x 1/2
14 2327532 Basket Assembly,
Freezer
15 2207454 Nut, Hex
16
W10001190
Washer
17
W10135775
Screw, 5/16−24 x 1
(Basket to Slide)
18 2258903 Cap, Door (4)
Corner
