OVEN DOOR PARTS
5
For Models: KEBC147KBL07, KEBC147KWH07, KEBC147KSS07
(Black) (White) (Stainless)
W10160902
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 8303698 Door Liner
2 Hinge, Door
9760569 Right (Green)
9760570 Left (Green)
(Below hinges are
used on Stainless
models only)
9760571 Right (White)
9760572 Left (White)
3 4449247 Glass, Inner
4 4451720 Insulation, Door
5 4449743 Screw
6 3196184 Screw
7 9759223 Glass, Inner
8 3400832 Screw
9 4448520 Bumper, Door
10 4449809 Screw
12 Door Glass, Assy
8300836 Black
8300837 White
W10151060
Stainless
13 Door Handle
9760538 Black
9760539 White
9760537 Stainless
14 Bracket, Handle
4455803 Right
4455804 Left
15 9759229 Bracket(2nd Glass)
16 9759230 Bracket(3rd Glass)
19 4457101 Shield, Heat
20 4457130 Retainer, Glass
21 8300853 Seal, Door Top
22 4457112 Shield, Heat (Btm)
23 Retainer, Clip
4450863 Black
4450864 White
4451432 Stainless
24 9759226 Glass, Inner
