ELECTRONIC OVEN CONTROL
This manual covers different models. The oven you have purchased may have some or all of the items listed. The locations and
appearances of the items shown here may not match those of your model.
Display(s)
When power is first supplied to the oven, the clock will be
flashing the message “clock-enter time.” Time can be entered by
touching either CLOCK SET/START or START to allow operation.
To allow operation without setting a time, touch
CLOCK SET/START, START or OFF.
Lower Oven Display (combination oven models)
When the lower oven is in use, this display shows the oven
temperature, heat source(s) and start time. In addition, during
Timed Cooking, this display shows a time countdown and the
stop time (if entered).
If “Err” appears on the lower oven display, an error condition has
occurred. Call for service. See the “Assistance or Service”
section.
Time of Day, Timer Display
When the lower oven is not in use, this display shows the time of
day or time countdown.
Upper Microwave Oven Display
(combination oven models)
When the upper microwave oven is in use, this display shows the
upper oven heat source(s), cooking power, quantities, weights
and/or help prompts and time countdown.
If “Err” appears on the lower oven display, an error condition has
occurred. Call for service. See the “Assistance or Service”
section.
When the upper microwave oven is not in use, this display is
blank.
Start
START key begins all oven functions except Sabbath Mode. If the
Start key is not touched within 5 seconds after touching another
key, “START?” will appear on the lower oven display as a
reminder. Depending on your model, if the Start key is not
touched within 5 minutes after touching another key, the lower
oven display will return to inactive mode and the programmed
function will be canceled.
A.Oven settings
B.Lower oven display
C.Timer
D.Number keys
E.EasyConvect™ conversion
F. Convection cooking settings
G.Oven light
H.Self-clean
I.Timed cooking
J.Off
K.Start/control lock
L.Clock set/start
M.Options
N.Microwave controls
(see separate Use and Care Guide)
O.Upper microwave oven display
% OZ
FC LBS
POWER
TIMER
MAXIMUM TIME REMAINING
A
B
C
D
E
FG
H
I
J
K
L
M
N
O
Lower Oven Display (combination oven models)
A.Oven cavity symbol
B.Time of day, timer display
Upper Microwave Oven Display (combination oven models)
A.Microwave oven cavity symbol
B.Timer display
A
B
% OZ
FC LBS
POWER
TIMER
MAXIMUM TIME REMAINING
A
B
