Manual abstract:
· Slide range back so rear range foot is under anti-tip bracket. Range Foot IMPORTANT SAFETY INSTRUCTIONS s This range is equipped with a three-
prong grounding WARNING: To reduce the risk of fire, electrical plug for your protection against shock hazard and shock, injury to persons, or damage
when using the should be plugged directly into a properly grounded range, follow basic precautions, including the receptacle. Do not cut or remove the
grounding prong following: from this plug. s WARNING: TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE s Disconnect the
electrical supply before servicing the SECURED BY PROPERLY INSTALLED ANTI-TIP appliance. DEVICES. TO CHECK IF THE DEVICES ARE s Never
Use the Range for Warming or Heating the INSTALLED PROPERLY, SLIDE RANGE FORWARD, Room. LOOK FOR ANTI-TIP BRACKET SECURELY s
Injuries may result from the misuse of appliance doors ATTACHED TO FLOOR, AND SLIDE RANGE BACK or drawers such as stepping, leaning, or sitting
on the SO REAR RANGE FOOT IS UNDER ANTI-TIP doors or drawers. BRACKET. s Maintenance Keep range area clear and free from s CAUTION: Do
not store items of interest to combustible materials, gasoline, and other flammable children in cabinets above a range or on the vapors and liquids. backguard
of a range children climbing on the s Storage in or on the Range Flammable materials range to reach items could be seriously injured.
should not be stored in an oven or near surface units. s Proper Installation The range, when installed, must s Top burner flame size should be adjusted so it
does be electrically grounded in accordance with local not extend beyond the edge of the cooking utensil. codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70. In Canada, For self-cleaning ranges the range must be electrically grounded in accordance s Before Self-Cleaning
the Oven Remove broiler pan with Canadian Electrical Code. Be sure the range is properly installed and grounded by a qualified technician.
and other utensils. Wipe off all excessive spillage before initiating the cleaning cycle. SAVE THESE INSTRUCTIONS 4 PARTS AND FEATURES This manual
covers several different models. The range you have purchased may have some or all of the items listed. The locations and appearances of the features shown
here may not match those of your model.
Control Panel REAR FRONT FRONT REAR 1 2 1. Left Rear Control Knob 2. Left Front Control Knob 3 3. Electronic Oven Control 4 4. Right Front Control
Knob 5. Right Rear Control Knob 5 Range 1. Surface Burner Cooking Area 2. Control Panel 3. Anti-Tip Bracket 4. Model and Serial Number (behind left side
of drawer) 5.
Storage Drawer 6. Backsplash (on some models) 7. Oven Vent 8. Automatic Oven Light Switch 9. Broil Burner (not shown) 10. Door Gasket 11. Oven Rack
12. Bake Burner (not shown) 13. Self-Clean Latch Parts and Features not shown Oven Door Window Oven Light Broiler Pan and Grid Broiler Pan Support
(on some models) Roasting Rack Temperature Probe (on some models) 5 COOKTOP USE Power failure Cooktop Controls In case of prolonged power
failure, the surface burners can be lit manually. Hold a lit match near a burner and turn knob counterclockwise to LITE.
After burner lights, turn knob to setting. WARNING REMEMBER: When range is in use or (on some models) during the Self-Cleaning cycle, the entire
cooktop area may become hot. Sealed Surface Burners Fire Hazard Do not let the burner flame extend beyond the edge of the pan. Turn off all controls when
not cooking. Failure to follow these instructions can result in death or fire.
Electric igniters automatically light the surface burners when control knobs are turned to LITE. The left front and right rear burners provide the highest heat
setting. The left rear and right front burners allow more accurate simmer control at the lowest setting. Before setting a control knob, place filled cookware on
the grate. Do not operate a burner using empty cookware or while the grate is unoccupied.
1 2 3 4 To Set: 1. Push in and turn knob counterclockwise to LITE. All 4 surface burners will click. Only the burner with the control knob turned to LITE will
produce a flame. 2. Turn knob anywhere between HI and LO..
Your user manual
KITCHENAID KGRT607
