LOWER UNIT AND TUBE PARTS
24
For Model: KSSC36QTS02
(Stainless Steel)
W10174663
Illus. Part
No. No. DESCRIPTION
1 9791833 Clip, Thermistor
2 486194 Screw
3
W10157752
Bracket
4 2309076 Suction Tube
5 2309070 Tube, Connect
(Drier/Restrictor)
6 2320615 Drain Pan Assy.
7
W10151288
Cover, Wiring
8
W10153595
Cover, Box
9 2307686 Tube, Discharge
10 2188820 Thermistor
11 2306092 Evaporator
12
W10140160
Heater, Defrost
13 1113048 Clamp, Heater (2)
14
W10139908
Seal, Return Air
15 2220832 Gasket, Evaporator
16 2155774 Wire Tie
17 2215691 Clip, Heat
Exchanger
18 2320554 Support, Drain Pan
19
W10160981
Bracket Assembly,
Air Return
