LOWER UNIT AND TUBE PARTS
24
For Model: KSSC42QTS03
(Stainless Steel)
W10221113
Illus. Part
No. No. DESCRIPTION
1 2215648 Damper, Heater
2 486194 Screw
3
W10157752
Bracket
4 2309076 Suction Tube
5 2309070 Tube, Connect
(Drier/Restrictor)
6
W10196999
Drain Pan Assy.
7
W10151288
Cover, Wiring
8
W10153595
Cover, Box
9
W10121371
Tube, Discharge
10 2188820 Thermistor
11
W10205101
Evaporator Assy
12
W10140161
Heater, Defrost
13 1113048 Clamp, Heater (2)
14
W10157882
Seal, Return Air
15 2220832 Gasket, Evaporator
16 2155774 Wire Tie
17
W10169509
Clip, Heat
Exchanger
18 2320554 Support, Drain Pan
19 9791833 Clip, Thermistor
20 2169104 Insulation, Sound
21 304392 Screw 8−18 x 1/2
