FREEZER DOOR PARTS
16
For Model: KSSC48FTS00
(Stainless Steel)
W10136457
Illus. Part
No. No. DESCRIPTION
1 2252328 Freezer Door
(Includes #14)
2 2306398 Plate, Door−Handle
3 2302879 Hinge, Bottom
4 489282 Screw
5 2266854 Hinge, Top
6 2316804 Spacer−Door,
Top & Bottom
7 2222810 Door Gasket,
Magnetic
8 2316868 Handle, Door
9 2309056 Spacer, Door−Skin
(Handle Side)
10 2307757 Skin, Door
11 Screw
8281250 Stainless Steel
12 2005433 Spacer, Door−Skin
(Top)
13 488568 Screw
14 2004933 Spacer, Door−Skin
(Bottom)
15 2005030 Spacer, Door−Skin
(Hinge Side)
16 308544 Screw, Handle
17 2005323 Filler, Door
18 2258951 Brace, Door Corner
19 2222777 Bin, Door (6)
