LOWER UNIT AND TUBE PARTS
20
For Model: KSSO42FTX02
(Etched Aluminum)
W10178093
Illus. Part
No. No. DESCRIPTION
1 486194 Screw
2
W10157752
Bracket
3 2309076 Suction Tube
4 2309070 Tube, Connect
(Drier/Restrictor)
5 2320615 Drain Pan Assembly
6
W10151288
Cover, Wiring
7
W10153595
Cover, Box
8
W10121371
Tube, Discharge
9 2306093 Evaporator
10
W10140161
Heater, Defrost
11 1113048 Clamp, Heater (2)
12
W10139908
Seal, Return Air
13 2220832 Gasket, Evaporator
14 4389107 Wire Tie
15
W10169509
Clip, Heat
Exchanger
16 2320554 Support, Drain Pan
18 9791833 Clip
19
W10160981
Bracket Assembly,
Air Return
