MOTOR AND ICE CONTAINER PARTS
14
For Model: KSSP36QMS03
(Stainless Steel)
W10115020
Illus. Part
No. No. DESCRIPTION
1 2222960 Ice Bin
2 2222959 Crusher Bin
3 2258222 Auger
4 2258220 Washer, Auger
5 1119007 Spacer, Flat (6)
6 2255460 Cover, Crusher
7 2257024 Blade, Rotary
8 1119005 Spacer, Step (2)
9 2257020 Blade, Fixed
10 2257023 Blade, Rotary
11 2198602 Block, Blade
12 489229 Roll Pin
13 2257022 Blade, Rotary
14 489235 Washer, Plain
15 2198661 Washer, Coupling
16 2188918 Coupling, Top
17 8281164 Screw
18 3400065 Screw
19 2252265 Button, Bin
20 2252206 Latch, Bin
21 2198608 Spring, Latch
22 2198671 Screw (2)
23 8281163 Screw
24 2188919 Holder
26 2198628 Seal
30 2188916 Drive Shaft
32 2315546 Dispenser, Motor
33 2222862 Cover
36 2315559 Sleeve. Coupling
