DISPENSER AND FRONT PARTS
Illus. Part
No. No. DESCRIPTION
16
For Model: KSSS36DAX04
4379205
1 1107943 Housing, Dispenser
2 987049 Bracket, Water
Fitting
3 2155018 Water Fitting
Assembly (Includes
Water Tube)
4 487916 Screw, 8 x 3/8
5 Water Tube
(See Item #3)
9 488316 Screw, 8−18 x 3/4
10 987048 Grommet
11 2001334 Heater, Ice
Dispenser
12 2147167 Ice Door Mechanism
13 2147168 Door, Ice
14 1129333 Shroud
16 489000 Screw, 9−12 x 1/2
17 1127421 Lever, Ice
Dispenser
19 987917 Bearing, Clip
20 2159196 Lever, Water
Dispenser
21 488307 Washer
22 983696 Spring, Lever
23 983697 Bearing, Lever
24 1120581 Delay Mechanism
25 1107454 Bracket, Control
26 841336 Switch
27 984683 Insulation, Switch
28 488361 Screw, 4−40 x 1
29 987265 Lamp Holder
30 488500 Screw, 8−32 x 3/8
31 851386 Light Switch
32 1107457 Plunger, Extension
33 983986 Spring, Plunger
34 983987 Retainer, Pin
35 2001350 Wiring Harness,
Door
36 984494 Wiring Shield
37 1118269 Guiding, Ice
38 1119056 Glass Stop
39 489197 Screw
40 487052 Screw
41 851389 Light Bulb
42 2001478 Front Cover,
Housing
44 1112836 Cover, Dispenser
Opening
45 2001475 Trim, Front (2)
46 487052 Screw, 8−15 x 1/2
47 983900 Grille, Overflow
48 934316 Switch
49 2001481 Overlay, Cover
53 487944 Washer (2)
54 488568 Screw (2)
55 482672 Seal
