UPPER UNIT PARTS
18
For Model: KSSS36DBX01
4379647
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 2002506 Assembly, Unit
Base
2 2163787 Clip, Compressor
Mounting (4)
3 483146 Compressor
(Includes Items
7, 8, 9, 10,
11 & 12)
(Also Order
876765 Tube Kit)
4 680975 Washer
6 2163786 Grommet, Mounting
7 2172890 Wire Assembly
8 2154760 Overload
(Includes Relay)
9 1108115 Terminal Cover
10 938384 Strap, Cover
11 Relay
(See Overload)
12 2169137 Capacitor
14 486899 Screw
15 487869 Screw
16 1113015 Condenser
17 943447 Grommet (4)
18 1113019 Clamp (4)
19 487522 Screw
20 1113228 Wire Tie (2)
21 1108023 Drier
22 2000358 Mounting Bracket,
Motor
23 2002409 Motor, Fan
24 2000352 Blade, Fan
25 2000351 Orifice, Fan
26 1113303 Gasket, Orifice
27 489399 Screw (3)
28 489368 Screw
29 486692 Speed Nut
30 2162044 Defrost Timer
31 488911 Screw
32 2000645 Sleeve,
Condenser
34 1113059 Process, Tube
35 486194 Screw
36 2000853 Cover, Fan
37 2001878 Cover, Condenser
38 1113076 Extension, Housing
39 937360 Service Cord
40 2001503 Seal Strip (2)
41 1113162 Clamp, Cord (2)
42 1113229 Switch, Power
Disconnect
43 488879 Screw, Ground
44 653035 Clip, Cord Plug
45 2001077 Wiring Harness,
Unit Compartment
47 2001079 Gasket (2)
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
8.5 oz.
(R−12)
