For Model: KSSS42DAW03
4379165
18
DISPENSER AND FRONT PARTS
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
20 2159199 Lever, Water
Dispenser
21 488307 Washer
22 983696 Spring, Lever
23 983697 Bearing, Lever
24 1120581 Delay Mechanism
25 1107454 Bracket, Control
26 841336 Switch
27 984683 Insulation, Switch
28 488361 Screw, 4−40 x 1
29 987265 Lamp Holder
30 488500 Screw, 8−32 x 3/8
31 851386 Light Switch
32 1107457 Plunger, Extension
33 983986 Spring, Plunger
34 983987 Retainer, Pin
35 2001350 Wiring Harness,
Door
36 984494 Wiring Shield
37 2147479 Guide, Ice
38 2147480 Glass Stop
39 488892 Screw
40 487052 Screw,
8−15 x 1/2 (6)
41 851389 Light Bulb
42 2001414 Front Cover,
Housing Assembly
(Includes Item 49)
44 1112836 Cover, Dispenser
Opening
45 2001160 Trim, Front (2)
46 487052 Screw, 8−15 x 1/2
47 1126120 Grille, Overflow
48 934316 Switch
49 2001176 Overlay, Cover
50 489098 Union
51 487857 Nut−Ball Sleeve
52 488794 "O" Ring Seal
53 487944 Washer (2)
54 488568 Screw (2)
55 482672 Seal
1 1124715 Housing, Dispenser
2 987049 Bracket, Water
Fitting
3 2155020 Water Fitting
Assembly (Includes
Water Tube
4 487916 Screw, 8 x 3/8
5 Water Tube
(See Item #3)
6 841707 Insert, Tube
9 488316 Screw, 8−18 x 3/4
10 987048 Grommet
11 2001334 Heater, Ice
Dispenser
12 2147167 Ice Door Mechanism
15 2147168 Ice Door
16 489000 Screw, 9−12 x 1/2
17 2155815 Lever, Ice
Dispenser
18 1129333 Shroud, Control
19 987917 Bearing, Clip
