G3503-[ ] POWER WAVE 450 WATER COOLER UPGRADE KIT
Recommended Spare Parts are Highlighted in Bold
Powerwave 450 Water Cooler Upgrade Assembly, G3503 & -1 1 X
Includes:
1 Base Assembly (G3503 Only) S24504-1 1 X
1 Base Assembly (G3503-1 Only) S24504-36 1 X
2 Motor S24504-2 1 X
3 Fan Blade S24504-3 1 X
4 Pump with Torque Coupling S24504-4 1 X
5 V-Clamp, Pump S24504-5 1 X
6 Torque Coupling, Pump S24504-6 1 X
7 Pump Inlet Strainer S24504-7 1 X
8 Heat Exchanger S24504-8 1 X
9 Pressure Switch S24504-9 1 X
10 Solid-State Relay S24504-10 1 X
11 Electrical Harness, Motor S24504-11 1 X
12 Electrical Harness, Pressure Switch & Relay S24504-12 1 X
13 Fan Shroud (G3503 Only) S24504-13 1 X
13 Fan Shroud (G3503-1 Only) S24504-37
14 Quick Disconnect Fitting S24504-14 2 X
15 Quick Disconnect Bracket with Label S24504-15 1 X
16 Reservoir (G3503 Only) S24504-16 1 X
16 Reservoir (G3503-1 Only) S24504-38 1 X
16 Replacement Reservoir & Fan Shroud (G3503 Only) S24504-39 1 X
17 Reservoir Inlet Strainer (G3503 Only) S22067-3 1 X
17 Reservoir Inlet Strainer (G3503-1 Only) S24504-40 1 X
18 Reservoir Cap (G3503 Only) S22067-2 1 X
18 Reservoir Cap (G3503-1 Only) S24504-41 1 X
19 Reservoir Elbow Fitting S24504-34 2 X
20 Reservoir Sealing Bushing S24504-35 2 X
21 Hose, Pump Inlet S24504-17 1 X
22 Hose, Pump Outlet S24504-18 1 X
23 Hose, Heat Exchanger Inlet (G3503 Only) S24504-19 1 X
23 Hose, Heat Exchanger Inlet (G3503-1 Only) S24504-42 1 X
24 Hose, Heat Exchanger Outlet S24504-20 1 X
25 Hose, Reservoir Inlet (G3503 Only) S24504-21 1 X
25 Hose, Reservoir Inlet (G3503-1 Only) S24504-43 1 X
26 Hose Clamp S24504-22 10 X
27 Hydraulic Manifold S24504-23 1 X
28 Manifold Inlet Fitting, 1/4 NPT to 3/8 ID Hose Barb S24504-24 1 X
29 Orifice Fitting, 1/89 NPT to 3/8 ID Hose Barb S24504-25 1 X
30 Pump Elbow Fitting S24504-26 2 X
31 Screw, Reservoir (G3503 Only) S24504-27 4 X
31 Screw, Reservoir (G3503-1 Only) S24504-45 1 X
32 Internal-tooth Star Washer, Motor (Not Shown) S24504-28 4 X
33 Warranty Label (Not Shown) S24504-29 2 X
34 Data Plate (G3503 Only) S24504-30 1 X
34 Data Plate (G3503-1 Only) S24504-44 1 X
35 Cable Holder, Push Mount S24504-31 2 X
36 Grommet Edging, Heat Exchanger S24504-32
1.75in.
X
37 Trim, Motor Mount S24504-33
1.5in.
X
39 Platform (Not used on 450 w/stand) G2391 1 X
40 Axle M8809-129 1 X
41 Wheel S13127-3 2 X
42 Push Nut T12570-2 2 X
43 Base Assembly L8860 1 X
44 Caster S11124-4 2 X
44A Thread Forming Screw S9225-28 8 X
7-26-99
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-261-K.3
ITEM DESCRIPTION PART NO. QTY. 123456789
P-261-K.3
#
#
#
#
