OVEN/BODY
No. Part No. Description
Section:
Series Qty
- 7401P037-60 BLOCK, TERMINAL Note: BOARD, TERMINAL 10 1
1 4005F152-51 COVER BOX WALL OVEN Note: COVER, BOX 10 1
- 7101P356-60 SCREW Note: SCREW, COVER 10 3
- 8008P004-60 GROMMET 10 2
2 4006W077-19 BOX, FLUE ASSY Note: BOX, FLUE 10 1
- 7101P287-60 SCREW, METAL GROUNDING Note: SCREW, FLUE BOX 10 4
3 74001988 BACK, MAIN 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, BACK 10 5
- 74001883 INSULATION, WRAPPER 10 1
4 74001850 INSULATION, WRAPPER Note: INSULATION, TOP & BACK 10 1
5 N 74002963 CORD, POWER 11 1
5 N 74001926 CORD, POWER 10 1
- 7101P356-60 SCREW Note: SCREW, PANEL 10 16
6 2618F115-51 PANEL, SIDE (RT) 10 1
6 2618F116-51 PANEL, SIDE (LT) Note: (LT) 10 1
7 74001882 HINGE, DOOR Note: (LWR) 10 2
7 74001856 HINGE ASSY. Note: HINGE, DOOR (UPR) 10 2
- 7101P115-60 SCREW Note: SCREW, HINGE ASSY. 10 8
7 74004059 HINGE, DOOR Note: HINGE, DOOR (UPR) 15 2
8 74001903 TRIM, SIDE (LT-BLK) Note: (LT-BLK) 10 1
8 74001902 TRIM, SIDE (RT-BLK) Note: EXTRUSION, SIDE (RT-BLK) 10 1
- 7103P039-60 NUT, SNAP (ROUND-WHT) Note: NUT, SNAP (1/16" X 1/2") 10 2
- 7101P040-60 SCREW (1/2") Note: SCREW, EXTRUSION (BLK) 10 2
- 7101P041-60 SCREW (ZINC) Note: (ZINC) 10 10
- 7101P058-60 SCREW Note: SCREW, BAFFLE 10 2
9 3601F109-45 BAFFLE Note: BAFFLE, OVEN FRONT 10 1
- 7103P100-60 NUT, TINNERMAN Note: NUT 10 2
10 7212P014-60 SEAL, DOOR (TOP) Note: SEAL, OVEN 10 1
11 7112P020-60 CLIP, OVEN FRONT 10 2
- 7101P356-60 SCREW Note: SCREW, CLIP 10 2
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, BASE 10 2
12 74001925 BASE, MAIN 10 1
- 7101P060-60 SCREW (10ABX1.0-ZN) Note: SCREW, BASE 10 4
13 74001846 EXTRUSION, BOTTOM (BLK) 10 1
- 7101P040-60 SCREW (1/2") Note: SCREW, EXTRUSION (BLK) 10 4
14 2205F005-19 BOTTOM, OVEN Note: BOTTOM, OVEN (LWR) 10 1
- 7101P287-60 SCREW, METAL GROUNDING Note: SCREW, SUPPORT (UPR) 10 2
15 N 5720A011-23 SUPPORT, OVEN BOTTOM Note: SUPPORT, OVEN BOTTOM (UPR) 10 1
- 7101P058-60 SCREW Note: SCREW, SUPPORT (LWR) 10 2
- 3807F029-80 SUPPORT Note: (LWR) 10 1
16 74004661 BOTTOM, UPPER OVEN Note: BOTTOM, OVEN (UPR) 17 1
16 2205F008-19 BOTTOM, OVEN Note: BOTTOM, OVEN (UPR) 10 1
17 7430P009-60 PROBE, OVEN SENSOR 10 1
- 74001530 SCREW (8AB1/2-NI) Note: SCREW, SENSOR 10 2
18 8003P009-60 BUMPER, DOOR (SQUARE) Note: BUMPER, DOOR 10 2
19 7408P035-60 RECEPTACLE, OVEN BULB Note: RECEPTACLE, LIGHT 10 2
20 7407P103-60 BULB, OVEN 10 2
21 7801P034-60 OVEN RACK Note: RACK, OVEN 10 1
21 7801P005-60 RACK Note: RACK, OVEN 10 2
22 Y3413F01619 INSERT, BROIL PAN 10 1
23 Y3401F02019 PAN, BROIL 10 1
- 7101P356-60 SCREW Note: SCREW, SUPPORT 10 2
24 N 3807F139-80 SUPPORT Note: SUPPORT, OVEN 10 1
25 4005F088-80 COVER Note: COVER, ACCESS 10 2
- 7101P356-60 SCREW Note: SCREW, COVER 10 4
- N 7111P007-60 CLAMP, WIRE 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
