Maytag MSD2550VES00 Refrigerator User Manual



ICEMAKER PARTS
20
For Models: MSD2550VEW00, MSD2550VEB00, MSD2550VES00, MSD2550VEU00
(White) (Black) (Stainless) (Stainless VCM)
W10197412
Illus. Part
No. No. DESCRIPTION
1 489084 Screw
2 2256096 Fitting, Water
Tube
3 628379 Clip, Fuse
4 489478 Screw
5 2315534 Filter Valve Asm
6 2208136 Clip, Tube
7 2174358 Cover
8 488649 Screw
9
W10122527
Mold & Heater
Assembly (Also
Order 542638
Silicone Grease)
10 2304969 Fill Cup
11 627843 Ejector
12 2198598 Ice Stripper
13 2194712 Support
14 2315522 Retainer,
Thermostat
15 627985 Thermostat (Also
Order 542369
Cement
Alumilastic)
16 8533917 Screw
17 2303583 Bracket, Ice Maker
Mounting
18 489276 Screw
19 2187467 Harness, Wiring
20 626691 Module Assembly
(Includes Items
21 & 22)
21 626683 Motor
22 489136 Screw
100
W10190960
Icemaker Assembly
