PS570 & PS570S
USA & Std. Export
VI. GAS BURNER SYSTEM - ORIGINAL CONFIGURATION (with solenoid valve)
1 1 27170-0011 BLOWER AND MOTOR
2 1 42810-0087 KIT, EXTERNAL AIR SHUTTER
3 1 42400-0640 KIT, PITOT TUBE
4 1 27170-0223 VENTURI WITH TARGET
5 1 42810-0117 KIT, PILOT ASSEMBLY WITH IGNITOR
6 1 27170-0204 PILOT SHIELD
7 1 27170-0264 BRACKET, PILOT MOUNTING
8 1 38284 FITTING, PILOT TUBING
9 A/R 15125-0002 TUBING, ALUMINUM, 1/4"/6.4mm O.D.
10 1 36920 FITTING, BULKHEAD
11 1 38279 ORIFICE HOLDER/INLET CONNECTOR
12 1 38280 WINDOW PLUG
13a -- 42810-0127 KIT, PS570S GAS CONVERSION, PROPANE
TO NATURAL GAS OPERATION (INCLUDES
ITEMS 14a, 15a, 16a, AND ALL PARTS AND
INSTRUCTIONS FOR CONVERSION)
14c 1 22176-0014 MAIN ORIFICE, NATURAL GAS, 0.250"
(6.35mm)
15a 1 22174-0011 PILOT ORIFICE, NATURAL GAS, 0.028"
(0.71mm)
16a 1 22174-0006 BYPASS ORIFICE, NATURAL GAS, 0.065"
(1.65mm, #53 drill)
ITEM QTY. P/N DESCRIPTION ITEM QTY. P/N DESCRIPTION
13b -- 42810-0124 KIT, PS570S GAS CONVERSION, NATURAL
GAS TO PROPANE OPERATION (INCLUDES
ITEMS 14b, 15b, 16b, AND ALL PARTS AND
INSTRUCTIONS FOR CONVERSION)
14b 1 22176-0015 MAIN ORIFICE, PROPANE, 0.152"
(3.86mm)
15b 1 22174-0010 PILOT ORIFICE, PROPANE, 0.018"
(0.46mm)
16b 1 22174-0009 BYPASS ORIFICE, PROPANE, 0.034"
(0.86mm, #62 drill)
17 2 22450-0259 HOSE CLAMP
18 1 37210-0026 BRACKET, HOSE AND BURNER MOUNTING
19 1 22450-0255 AIR DUCT, FLEXIBLE
20 A/R 38290 TUBING, SILICONE RUBBER, 1/4"/6.4mm DIA.
21 1 27159-0019 IGNITION/SENSOR WIRE
22 1 30185 KIT, PILOT TEE 1/4"/6.4mm
23 A/R 15125-0002 TUBING, ALUMINUM, 1/4"/6.4mm O.D.
24 1 28091-0017 VALVE, SOLENOID, 1/2"
25 1 42810-0121 KIT, COMBINATION GAS VALVE (SAFETY
REGULATOR), 1/2"
26 1 23115-0009 VALVE, SHUTOFF 1/2"
27 1 41649 BRACKET, PIPE MOUNTING 1-1/4"
28 1 23051-0003 UNION, PIPE 1/2"
29 1 23051-0012 UNION, PIPE 1-1/4"
