MQ-MIKASA MVH-304DSB PLATE COMPACTOR — PARTS & OPERATION MANUAL — REV. #2 (11/16/05) — PAGE 33
MVH-304DS — B BASE AND ENGINE ASSY.
VIBRATING PLATE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 456115310 BASE (L90) 1
2 914410013 ENGINE ASSY. (L100EE-DEVMK3) 1
7 456115040 BELT COVER (IN) ...................................... 1......... UP TO S/N G4384
7 456116070 BELT COVER (IN) ...................................... 1......... FROM S/N G4385 AND UP
8 001220830 BOLT 8X30 T 4
8 001220835 BOLT 8X35 T 4
9 030208200 WASHER M8 4
10 031108160 WASHER M8 4
11 456445120 COVER SEAL 125D 1
12 456445721 SPACER 25-32-21 1
13 456335600 CLUTCH AY W/ FAN 1
14 951400110 KEY 7X77X35 1
15 455444351 WASHER,CLUTCH 1
16 030208200 WASHER M8 1
17 001220825 BOLT 8X25 T 1
18 070200363 V-BELT B-36 GREEN/HDPF536 1
19 456115130 BELT COVER (OUT) 1
20 001221052 BOLT 10X60 T 4
22 030210250 WASHER M10 4
23 0311-10160 WASHER M10 4
24 456115050 GUARD FRAME 1
25 001221230 BOLT 12X30 T 4
26 030212300 WASHER M12 4
27 456335520 PULLEY B1-105 W/ FAN 1
28 456437920 WASHER, PULLEY 1
29 001221235 BOLT 12X35 T 1
30 0302-12300 WASHER M12 1
41 031110160 WASHER M10 1
