FV-08VKSL2
No. Part No. Part Name Q'ty Remark
1 FFV3402114S Grille Unit 1
2 FFV3420023S Lighting Unit 1
3 FFV0930017S Circuit Unit 1
4 FFV6400005S Ventilation Unit 1
5 FFV1600107S Frame Unit 1
6 FFV0000085S Adapter Unit 1
7 FFV0800001S Casing Support 1
A FFV7000011S Machine Screw 3
For Fixing Lighting Unit & Adapter Unit,Included In Accessory A
B FFV7000097S Truss Screw 2 For Fixing Circuit Unit
C FFV7000065S Bind Screw 3 For Fixing Ventilation Unit
D FFV7000108S
Truss Tapping Screw
1 For Fixing Casing Support
E FFV7000063S Truss PC Screw 1
For Fixing Lighting Unit,Included In Accessory A
No. Part No. Part Name Q'ty Remark
8 FFV1600108S Frame Assy. 1
9 FFV0800001S Casing Support 3
10 FFV0420024S Bracket Cover 1
F FFV7000064S Bind Screw 3 For Fixing Casing Support
G FFV7000018S Truss Tap Screw 4 For Fixing Bracket Cover
No. Part No. Part Name Q'ty Remark
11 FFV0900042S Connector Plate 1
12 FFV0900043S Connector Assy. 1
13 FFV2800012S Junction Box Cover 1
H FFV7010002S Plain Washer 1
I FFV3402103S Earth Lead Wire 1
J FFV7010028S Spring Washer 1
K FFV7000006S Bind Screw 1 For Fixing Earth Lead Wire
L FFV7000091S Pan Tap Screw 2
For Fixing Connector Plate & Junction Box Cover
No. Part No. Part Name Q'ty Remark
14 FFV3730056S Motor Unit 1
15 FFV3730026S Motor Support 1
16 FFV0400088S Blade 1
17 FFV4670003S Blade Set Plate 1
18 FFV7020021S Nut 1
19 FFV0790025S Casing 1
20 FFV0420026S Fix Plate 1
21 FFV0740007H Cord Clip 1
B FFV7000097S Truss Screw 1 For Fixing Cord Clip
E FFV7000063S Truss PC Screw 6 For Fixing Motor Support & Fix Plate
M FFV7000109S Motor Screw 4 For Fixing Motor Unit
Main Body Section
Frame Unit
Adapter Unit
Ventilation Unit
!
!
!
!
!
!
!
