3.Parts List
FV-10VSL3
7
Main Body Section
No. Part No. Part Name Q'ty Remark
E FFV7000080S Plus Bind Screw 2 For Fixing Casing
F FFV7000191S Bind Screw 1 For Fixing Light Kit Cover Assembly
G FFV7000105S Pan Tap Screw 1 For Fixing Lamp Holder Section
H FFV7000140S Pan Tap Screw 2 For Fixing Spring Set Plate
Main Labels
No. Part No. Part Name Q'ty Remark
31 FFV4020793S Name Plate 1 Stuck On Casing
32 FFV2260003S UL Mark 1 Stuck On Frame Assembly
33 FFV0810011S Caution Label 1 1 Stuck On Frame Assembly
34 FFV6730056S Warning Label 1 Stuck On Grille Unit
35 FFV4730001S T24 Mark Label 1 Stuck On Grille Unit
Packing Section
No. Part No. Part Name Q'ty Remark
36 FFV4710365S Grille Case Assembly 1
37 FFV4710366S Right Pad 1
38 FFV4710367S Left Pad 1
39 FFV2540166S Installation Instructions 1 English,For USA Market / CANADA Market
40 FFV2540167S Installation Instructions 1 Spanish,For USA Market
(40) FFV2540168S Installation Instructions 1 French,For CANADA Market
41 FFV0010231S Accessory A 1
42 FFV9001072S Packing Case Assembly 1
