FV-11VH2
17
No. Part No. Part Name Q'ty Remark
25 FFV7000147S Blade Fixing Screw 1 For Fixing Blade Assy.
26 FFV0400092S Blade Assy. 1 For Circulation Unit
27 FFV3730048S Motor Support C 1
28 FFV3700296S C Motor Assy. 1 120V,60Hz
29
FFV0790056S
Casing Assy. C 1
A FFV7000153S Truss Tap Screw 3 For Fixing Motor Support C
M
FFV7000173S
Pan Tap Screw 2 For Fixing C Motor Assy.
No. Part No. Part Name Q'ty Remark
30 FFV2220016S Heater Unit 1
31
FFV2220017S Heater Box Cover 1
32 FFV2220018S Heater Box 1 1
33 FFV0720008S Coed Bushing 2
34
FFV0960001S Nylon Clamp 1
35
FFV2220015S
Heater Box 2 Assy. 1
A FFV7000153S Truss Tap Screw 8
K FFV7000009S Truss Tap Screw 1 For Fixing Nylon Clamp
No. Part No. Part Name Q'ty Remark
36
FFV2220020S
Heater Fix Plate Assy. 1
37
FFV5850017S
Thermostat Assy. 1
38
FFV5820027S
Terminal 1
39
FFV0940006S
Cut Off Plate 1 For Fixing Cord Assy. C
40
FFV0730027S PCB Cord Assy.
1
41
FFV0730028S
Cord Assy. C 1
42 FFV2220019S Heater Assy. 1
A FFV7000153S Truss Tap Screw 6 For Fixing Cut Off Plate & Heater Assy.
C FFV2530003S Tie 1 2
N FFV7000039S Pan Tap Screw 2 For Fixing Thermostat Assy.
O
FFV7000155S
Pan Tapping Screw 1 For Fixing Terminal
No. Part No. Part Name Q'ty Remark
43 FFV3700298S V Motor Assy. 1 120V,60Hz
44
FFV0900024S
Connector 2
45
FFV3470001S
Butt Connector 1
46 FFV0750107S Capacitor 1 250V 3.0uF
47
FFV0730029S
Cord Assy. V 1
48 FFV3730049S Motor Support V 1
49 FFV0400089S Blade B 1 For Ventilation Unit
50 FFV4670003S Blade Set Plate 1
51 FFV7020021S Nut 1 For Fixing Blade B
52 FFV0790057S Casing Assy. V 1
53 FFV3700297S V Motor Unit 1
R FFV7000174S Truss Tap Screw 2 For Fixing V Motor Assy.
Casing Section
Ventilation Unit
Heater Section
Heater Unit
!
!
!
!
!
!
!
!
!
!
!
!
!
