SM/SMBW 2000 Series™ Filter Installation and User’s Guide
How to Use the Filter Lid Opener Tool
1. Turn pump off.
2. Open the air relief valve and wait for tank water to drain into pool.
See Figure 4.
3. Remove the clamp ring.
4. Insert the filter lid opener as shown in Figure 5.
a. The tool fits
under the O-Ring.
5. Lift the tank lid with the filter lid opener in several places around the tank.
6. Consult page 7 for Filter Cleaning and pages 5 and 6 for Filter Operating
Instructions.
Lid
O-ring
Filter Lid Opener
(2)
Lift Up the
Filter Lid Opener
(1)
Insert the
Filter Lid Opener
Tank
The Pentair Water Pool and Spa Filter Lid Opener Tool may be used on any stainless steel filter tank
manufactured by Pentair Water Pool and Spa.
Pressure
Gauge
Air Relief
Valve
Lid
Clamp
Tank
Figure 4.
Figure 5.
