Model TURBOFRY 2000 - Gas Continuous Filtration Convection Fryer
SHORT FORM SPECIFICATION
Provide Pitco TF 2000 gas fired fryer. Fryer shall have continuous 10 gallon per minute
continuous filtration using high flow filters to effect convection frying. Fryer to have a high
input power burner and "U" shaped heat tube with heat recuperation system to transfer heat
to the cooking oil. Fryer to incorporate digital temperature control to maintain frying temperature
accurately and to control continuous filtration system. Frying cooking area to be 17-13/16" x
34" (45.24 cm x 86.36 cm) with a cooking depth of 4". Provide accessories as follows:
TYPICAL APPLICATION
Food service operations that require high product output, or that create large amounts of
breading sediment.
OIL CAPACITY
195 pounds (88.4 KG) / 25.4 Gal (95.3 L)
SHIPPING INFORMATION
732 pounds (332 KG) / 69.8 cubic feet ( 1.98 cubic meters)
PERFORMANCE CHARACTERISTICS
Cooks 260 lbs (117.9 KG) of fries per hour
Frying Area 17-13/16 x 34 (45.2 cm x 86.3 cm)
Filter Area 1200 square inches
Filters 10 gallons (37.5 L) per minute
ELECTRICAL
VOLTAGE/PHASE/HZ
Description 208-240/1/60
AMPS/EA
TF2000 UNIT WITH DIGITAL
SOLID STATE CONTROL AND
PUMP 2.8 - 3.5
COMPUTER (OPTIONAL) NO ADDITIONAL AMPS
NOTE: Requires 20 amp circuit breaker.
GAS CONSUMPTION
240,000 BTU's/Hour / 60,480 KCal
240 SCFM (Min.) Natural Gas Flow Rate at 7.0" W.C.
96 SCFM (Min.) LP Gas Flow Rate at 11.0" W.C.
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304, USA
(800) 258-3708 • (603) 225-6684 • FAX (603) 225-8472
L10-113 Rev. 02 04/00 Specifications subject to change without notice. Printed in U.S.A
