Project_________________________
Item No._________________________
Quantity_________________________
Pitco Frialator, Inc • P.O. Box 501, Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304
603-225-6684 • FAX: 603-225-8497 • www.pitco.com
L10-266 Rev 1 02/07 Printed in the USA
Model SSH, SSH55T and SSH75
Solstice Supreme Gas Fryer
STANDARD FEATURES & ACCESSORIES
Tank - stainless steel construction
Cabinet - stainless front, door and sides
Solstice Burner Technology, No blower or ceramics
Self Cleaning Burner & Down Draft Protection
Solid State T-Stat with melt cycle and boil out mode
Matchless Ignition with DVI drain valve interlock
Heavy duty 3/16” bottom door hinge
1 ¼” (3.2 cm) Full port drain valve for fast draining
Separate Manual gas shutoffs, for front servicing
Integrated flue deflector
9” (22.9 cm) adjustable legs, easier access to clean
Tube rack, allows crumbs & debris into cool zone
Removable basket hanger, requires no tools
Drain Line Clean out rod
Drain Extension
Fryer cleaner sample packet
Choice of basket options :
Twin Baskets
Full Basket
CONTROLS
Matchless Ignition automatically lights the pilot when the
power is turned on and saves you money during off times.
Solid State Thermostat with melt cycle and boil out mode.
Optional: Digital Controller with displaying 2 product timer
Optional: I-12 Computer with 12 product timer and flex time
DVI drain valve interlock safety system turns the heat off
preventing the oil from scorching and overheating.
Integrated gas control safety valve controls gas flow.
Temperature limit switch safely shuts off all heat if the
upper temperature limit is exceeded.
HIGH EFFICIENCY SERIES OF GAS FRYERS
For Energy Saving High Production frying specify Pitco
Model SSH55, SSH55T, SSH75 tube fired gas fryers with
Solstice Supreme Burner Technology which provides very
dependable atmospheric heat transfer and fuel saving
Energy Star
TM
**
performance without the need for complex
power blowers. This patented atmospheric burner system
with its long lasting alloy heat baffles reaches up to 70%
thermal efficiency and delivers lower flue temperatures. New
Self Clean Burner
(patent pending) goes through a daily 30
second cleaning cycle to keep your burners tuned to operate
in the most energy efficient manner. Ventilation troubles are
virtually eliminated with the Down Draft Protection
(patent
pending)
that safely monitors your fryer, making this a low
maintenance, highly reliable fryer.
MODELS AVAILABLE
SSH55 (40-50 lbs, 80KBtu/hr, 14” x 14” fry area)
SSH55T (20-25 lbs, 40KBtu/hr, 7” x 14” fry area
per side for this split vat fryer)
SSH75 (75 lbs, 105KBtu/hr, 18” x 18” fry area)
OPTIONS & ACCESSORIES (AT ADDITIONAL COST)
Digital Controller
I-12 Computer
Backup thermostat (only on Digital and I-12 computer)
Basket Lift (must be ordered with Digital Control or Computer)
(To meet AGA/CGA/CSA specification, must be ordered with
casters & installed with flexible gas hose w/restraining cable
)
Stainless Steel back (not available with basket lift)
9”(22.9 cm) adjustable,non-lock rear & front lock casters
Flexible gas hose with disconnect and restraining cable
Tank cover
Triple Baskets
Institutional Prison security package
BNB Dump Station
Filter System, see Supreme Filter spec sheet for details
TYPICAL APPLICATIONS
High Volume restaurants or multi-store restaurant chains
that require a Reliable, Highly Efficient EnergyStarTM**
rating, High Production Fryer with low operational energy
cost and lower annual maintenance and repair cost
Model SSH55, SSH55T and SSH75 Solstice Supreme Gas Fryer
SSH55
SSH75 with optional
Computer, Basket
Lift and casters
Patent Pending
**
on some
