operating _33
02 OPERATING
To remove
• Simply lift the bin up and pull straight out.
• Tilt up the front of the drawer and pull straight
out, and pull out the drawer after moving
slightly in the direction of the arrow.
To re-install
• Insert the drawer into the frame rails and push
back into place.
• Slide bin in above the desired location and
push down until it stops.
The drawers need to be removed before
the glass shelf above them can be lifted
out.
5. Flex Zone
To remove the Flex Zone – Pull the Flex door
out to full extension. Lift the Flex Zone up, pulling
it to your body with both hands.
To re-install the Flex Zone – Open the Flex door
to full extension. Tilt the front of the Flex Zone up,
place the back of the Flex Zone onto the rails, and
then lower the front until the whole Zone rests on
the rails.
When the Flex Zone or LED lighting is not
working, check the connectors [ ( 1 ), ( 2 )
shown below ] for cracks or leaks.
CAUTION
1
2
1. Refer to page 18 for disassembly
instructions.
2. Open the cap cover rail with a fl at-blade
screwdriver.
Using the doors
Ensure that the doors close all the way and are
securely sealed.
When the refrigerator door is only partially open, it
will automatically close. If the the door is opened
more than its auto close range, it will remain open.
You must close it manually.
REMOVING THE FREEZER
ACCESSORIES
1. Freezer Room Guard
To remove - Remove the freezer room guard ( 1 )
by lifting the guard up.
To re-install - Push down until the guard ( 1 )
locks into place.
1
2. Super Extended Drawer
To remove - Pull the drawer out to full extension.
