Instructions for the installer
22
16.FINAL OPERATIONS
After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids.
Following adjustment to a gas other than the preset one, replace the gas adjustment label fixed to the
appliance with the one corresponding to the new gas. This label is in the packet together with the
nozzles.
16.1 Regulation of the hob burner minimum level for natural gas
Light the burner and turn it to the minimum position . Remove the gas tap knob
and adjust the regulator screw inside or beside the tap rod (depending on the
model) until an even minimum flame is obtained. Put the knob back in place and
check the stability of the burner flame (the flame must not go out when the knob
is turned quickly from the maximum to the minimum setting). Repeat the
operation on all the gas taps.
For models with valves, keep the knob at minimum level for about 1 minute to keep the flame lit and to
activate the safety device.
16.2 Mounting the rear top skirtboard (where applicable)
• Loosen screws A located beneath the skirt.
• Loosen nuts B.
• Position the skirt above the top, taking care to align pins C with
holes D.
• Secure the skirt to the top by tightening screws E.
16.3 Wall fixing (where applicable)
• Stretch out the chain attached to the cooker horizontally so that
the other end touches the wall.
• Mark the wall in the position where the hole is to be drilled.
• Drill the hole, insert a wall plug and attach the chain.
• Move the cooker up against the wall.
914772495/ D
