Chapter 1 1
Features
Below is a brief summary of the computer’s many feature:
NOTE: The features listed in this section is for your reference only. The exact configuration of the system
depends on the model purchased.
Operating System
• Microsoft Windows 7 Home Premium X86/ X64
• Microsoft Windows 7 Home Basic X86/ X64
• Microsoft Windows 7 Starter x86
• Linux x-Window mode
• Free DOS
Processor
• Socket Type: None
• Processor Type:
• Intel Atom D400/D500 series CPU
• Atom D525+GT218
Chipset
• Intel NM10
• Design Criteria:
• Should meet Intel Pine Trial-D platform design guide
• Super I/O: ITE/8721
• Should support SST signal output
PCB
• 170mm*170mm (Proprietary)
Memory subsystem
• Socket Type: DDR III SO-DIMM connector
• Socket Quantity: 2
• Only support single channel
• Capacity support:
• 1GB / 2 GB DDRIII 800 SO-DIMM support (follow Intel Spec.)
• 1GB to 4GB Max memory support(follow Intel Spec.)
• Design Criteria:
• Should follow Pine Trail-D platform design guide
• Should meet Pine Trail-D BIOS Specification
System Tour
Chapter 1
