7. INSTALLATION OF EXP-06E
7.1 Overview of EXP-06E
The EXP-06E has two-reader port and one keypad port, capable of handling three
relay outputs. The EXP-06E is housed in a 16 AWG metal wall-mounted cabinet. The
static RAM consumes minimal power for storing memory and data. The EXP-06E is
compatible with PC using Access Control System.
The EXP-06E offers software- controlled features such as Time Zone, Key Zone,
Holiday, Programmable Zone, Cardholders database and Anti-passback control.
The EXP-06E has two types of battery backup: onboard memory and operational
power. The operational power battery, known as the Advanced Power Supply(APS),
gives the EXP-06E internal power fail capability.
7.2 Physical Requirement
External devices connect to the EXP-06E via ports located on the right and left sides
of the Connectors and the device types are listed in Table 1.1. See Figure 1.1.
The following table is External Devices Connectors
Devices Connectors
In Reader C1 (1-7)
Out Reader C3 (1-7)
Keypad C2 (2-8)
Alarm Relay Output C4 (R,Q)
Programmable Relay Output C4 (P,O)
Door Lock Relay Output C4 (N,M)
Door Sensor C4 (L,K)
Door Release Button C4 (J,K)
RS-232 Communication Port C4 (G,H,I)
RS-485 Communication Port C4 (E,F)
Power Supply DC2, COM C4 (A,B)
Event Printer Port C5 PRINTER
