VLAN Configuration
Page 9-7
VLAN Management Interface Options
The IntraSwitch VLAN configuration can be achieved through
either Console/Telnet operation or SNMP operation. Web based
management will be available soon. The following section
describes VLAN configuration by means of Console/Telnet
interface.
VLAN
Configuration
This section explains how to configure your IntraSwitch for
VLAN use after you have connected to Local Management
Interface using either an out-of-band Console or in-band Telnet
connection. When you first make this connection, the default
VLAN settings will be as shown in Table 9-1. To change these
settings, use the procedures that follow.
Table 9-1 System VLAN Default Settings
VLAN
Group #
Port Members VID MGMT Access
1 All ports untagged 0001 Enabled
2 No Ports 0002 Enabled
3 No Ports 0003 Enabled
4 No Ports 0004 Enabled
5 No Ports 0005 Enabled
6 No Ports 0006 Enabled
7 No Ports 0007 Enabled
8 No Ports 0008 Enabled
9 No Ports 0009 Enabled
10 No Ports 0010 Enabled
11 No Ports 0011 Enabled
