CONTENTS
SECTION PAGE
1. GENERAL………………………………………... 3
2. SITE REQUIREMENTS…………………………………. 4
3. CLEARANCES…………………………………………… 4-5
4. EXTRACTION……………………………………………. 6
5. ELECTRICAL CONNECTION………………………….. 7
6. SUPPLY CABLE - CONNECTION…………………… 8
7. OPERATING……………………………………………… 9
8. SAFETY CUT-OUT (RE-SET)………………………….. 10
9. GENERAL DIMENSION………………………………… 11
10. WIRING DIAGRAM………………………………………. 12
BKI ROTARY OVENS ARE MANUFACTURED ACCORDING TO THE
FOLLOWING STANDARD:
BSEN 60 335-2-42: 2002
NOTICE : SAFETY CUT-OUT
For added safety all Rotary Ovens have a built in thermal cut-out to
protect against over-heating through component failure or incorrect
use.
If for any reason the thermal cut-out operates, the oven will automatically
shut down and should be switched `OFF` disconnected from the mains
and allowed to cool.
NOTE: THE THERMAL CUT-OUT WILL NOT RESET AUTOMATICALLY.
The oven must not be re-used until it has been checked by a
Qualified electrician or BKI Appointed Service Agent.
