2001/2002-6
123
45
STOPWATCH MODE
The Stopwatch Mode lets you measure
elapsed time, split times, and two finishes. The
range of the stopwatch is 23 hours, 59
minutes, 59.9 seconds.
Note
• Entering the Player Mode while a stopwatch
timing operation is in progress automatically
stops the operation and resets the
stopwatch to all zeros.
Elapsed time measurement
Split time measurement
Two Finishes
Hours
Minutes
Seconds
1/10 second
Start Stop Re-start Stop Clear
Split releaseStart Split Stop Clear
Start Split
First runner
finishes.
Stop
Second runner finishes.
Record time of first
runner.
Split release
Record time of
second runner.
Clear
SETTING MODE
Use the Setting Mode to set the current time and date, and to reset the
seconds to 00.
To set the time and date
1. In the Timekeeping Mode, press MODE
three times to enter the Setting Mode.
• The seconds digits start to flash, which
indicates the setting screen.
• Each press of
moves the flashing around
the setting screen in the sequence shown
below.
Seconds
Hour
Minutes
Day
Month
Year
2. While a setting is flashing, use to change it.
• Holding down
changes the flashing setting at high speed.
• When setting the time using the 12-hour format, take care to set the time
correctly as am (no indicator) or pm (P indicator).
• The year can be set in the range of 2000 to 2039.
• The day of the week is automatically displayed in accordance with the date
(year, month, and day) settings.
3. When everything is the way you want it, press MODE to exit the setting
screen and return to the Timekeeping Mode.
• The watch’s built-in full automatic calendar automatically makes
allowances for different month lengths and leap years.
Resetting the Seconds Count to Zero
1. In the Timekeeping Mode, press MODE three times to enter the Setting
Mode.
• The seconds digits start to flash, which indicates the setting screen.
2. Press
to reset the seconds count to 00.
• Pressing
while the seconds count is in the range of 30 to 59 resets the
seconds to
00 and add 1 to the minutes. In the range of 00 to 29, the
minutes count is unchanged.
3. Press MODE to exit the setting screen and return to the Timekeeping
Mode.
Note
• The watch automatically exits the setting screen and returns to the
Timekeeping Mode if you do not perform any operation for about one
minute.
10 58
35
Action
Charge the battery.
Press the reset button
to reset the watch.
Download data to the
watch.
Plug in the earphones
correctly.
Increase the volume.
Charge the battery.
Move the watch away
from the appliance.
Stop using the device
or move the watch
away from the device.
Check the connection
and make sure it is
secure.
Check all connections
and make sure they
are secure.
Securely plug the AC
adaptor into an AC
outlet.
Contact your original
dealer or CASIO
distributor.
Possible Cause
Battery power is low.
There may be some problem
with the watch’s internal
system.
There is no MP3 data in
memory.
The stereo earphones are
not plugged in correctly.
The volume setting is too
low.
Battery power is low.
The watch may be too close
to a TV or other appliance
that generates strong
electromagnetic force.
The watch make be too close
to a mobile phone or other
device that generates radio
waves.
The USB cable may not be
connected properly.
The AC Adaptor or Interface/
Charger Unit may not be
connected properly.
The AC Adaptor may not be
plugged into an AC outlet.
The battery has reached the
end of its service life or it is
defective.
Problem
• Buttons do not
respond.
• Irregular display
Cannot playback or
cannot hear any
sound.
Static in the
playback
Cannot download
MP3 data.
Cannot charge the
battery.
Playback time
provided by a full
charge is short.
REFERENCE
Troubleshooting
Error Messages
Display
or
Possible Cause
The watch’s built-in Multi
Media Card may be
defective.
There is no MP3 data in
watch memory.
The MP3 data in watch
memory may be corrupted or
there may be a problem with
MMC formatting.
The play time of a track
exceeds the maximum of 99
minutes 99 seconds.
Action
Contact your original
dealer or CASIO
distributor.
Use the Link Soft to
download MP3 files to
the watch.
Use the Link Soft to re-
format watch memory
and download the MP3
data again.
Keep the play time of
any single track below
99 minutes 99
seconds.
