Connexions électriques (suite)
Fil de terre
Noir
Blanc
Blanc
Vert
Noir
Bleu
Interrupteur
d’éclairage
Figure B
Fil de terre
Noir
Blanc
Blanc
Vert
Noir
Bleu
Interrupteur
d’éclairage
Interrupteur
du ventilateur
Noir
Figure C
What You Have
Parts Quantity
1. Mounting Bracket 1
2. Down Rod Assembly 2
6" Rod Supplied
3. Canopy 1
4. Flange Cover 1
5. Fan Housing & Motor 1
6. Blade arms 5
7. Blades (sold separately) 5
8. Switch Housing Assembly 1
9. Balance Kit 1
12
3
6
Screw Package Quantity
S1. Wood Screws 2
S2. Screws (for Canopy) 3
S3. Bracket Screws & Washer 2
S4. Blade Screws 16
S5. Motor Screws (4 screws on motor) 11
S6. Wire Connectors 3
S7. Safety Bolt & Nut 1
S8. Pull Chains 1
S9 Switch Housing Screws 3
S10. "J" Hook 1
S11. Zip Tie 1
S2
S3
S6
S5
S1
S4
4
8
5
S10 S11
S9
S8
®
S7
7
