STK22C48
Document Number: 001-51000 Rev. ** Page 13 of 14
Package Diagrams
Figure 13. 28-Pin (300 mil) SOIC (51-85026)
Figure 14. 28-Pin (330 mil) SOIC (51-85058)
PIN1ID
0.291[7.39]
0.300[7.62]
0.394[10.01]
0.419[10.64]
0.050[1.27]
TYP.
0.092[2.33]
0.105[2.67]
0.004[0.10]
0.0118[0.30]
SEATINGPLANE
0.0091[0.23]
0.0125[3.17]
0.015[0.38]
0.050[1.27]
0.013[0.33]
0.019[0.48]
0.026[0.66]
0.032[0.81]
0.697[17.70]
0.713[18.11]
0.004[0.10]
114
15 28
*
*
*
PART#
S28.3 STANDARD PKG.
SZ28.3LEADFREEPKG.
MIN.
MAX.
NOTE:
1.JEDEC STDREFMO-119
2.BODY LENGTHDIMENSIONDOESNOT INCLUDEMOLD PROTRUSION/ENDFLASH,BUT
MOLDPROTRUSION/END FLASHSHALLNOTEXCEED 0.010in (0.254mm)PERSIDE
3.DIMENSIONS ININCHES
4.PACKAGE WEIGHT0.85gms
DOESINCLUDE MOLDMISMATCH ANDAREMEASUREDAT THEMOLDPARTINGLINE.
51-85026-*D
51-85058-*A
