w Select the parameter
Center Sp.
Front Sp.
Subwoofer
Surround Sp.
Surround back Sp.
4
ENTER the setting.
The Speaker Setup Menu reappears.
NOTE:
• Select “Large” or “Small” not according to the actual size of the speaker but according to the speaker’s
capacity for playing low frequency (bass sound below the frequency set for the Crossover Frequency)
signals. If you do not know, try comparing the sound at both settings (setting the volume to a level low
enough so as not to damage the speakers) to determine the proper setting.
(Remote control unit)
(Remote control unit)
(Remote control unit)
• Parameters
Large.................Select this when using speakers that have sufficient performance for reproducing bass
sound below the frequency set for the Crossover Frequency mode.
Small.................Select this when using speakers that do not have sufficient performance for reproducing
bass sound below the frequency set for the Crossover Frequency mode. When this is set,
bass sound with a frequency below the frequency set for the Crossover Frequency mode is
sent to the subwoofer.
None……..........Select this when no speakers are installed.
Yes/No…...........Select “Yes ” when a subwoofer is installed, “No” when a subwoofer is not installed.
2spkrs/1spkr .....Set the number of speakers to be used for the surround back channel.
If the subwoofer has sufficient low frequency playback capacity, good sound can be achieved even when
“Small” is set for the front, center and surround speakers.
2-1 Setting the type of speakers
• The composition of the signals output to each channels and the frequency response are adjusted
automatically according to the combination of speakers actually being used.
1
Select “Speaker Config.” at the Speaker Setup Menu.
