Temperature Scale LED - Illu
the current temperatures being displayed are
either in °C or °F; also used to display the clock
LED - Illuminates to indicate AM or PM
Button - Activates/deactivates a
Button - Allows the user to pro-
gram the unit or check the current program.
LED - Illuminates to indicate the cur-
CLOCK LED - Illuminates to indicate the cur-CLOCK
rent step that is being programmed into the
Buttons - Allows the user to set the clock and program the start and
The unit can be operated in COOL mode by pressing the C
ON/OFF button (LED illuminates).
NOTE: In COOL mode the unit can only be turned off by pressing the “C
OFF” button again, not by pressing the fan buttons.
Change the fan speed by pressing the HIGH or LOW fan buttons.
Change the temperature set point by pressing the SET TEMP buttons (
▼
▲
NOTE: When turning the unit on, the set point and fan speed are determined by the
last operating mode (program mode not included).
Operating in Fan Only Mode
The unit can also be operated in Fan Only mode by pressing either the HIGH or LOW
fan buttons (LED illuminates).
The unit can then be turned off by pressing the fan speed button that is illuminated.
Changing from Fan Only Mode to COOL Mode
mode can be activated while the unit is operating in Fan Only mode. To do
button (LED illuminates).
NOTE: The Fan Only mode will not operate after the C
After the COOL mode has been activated, the unit cannot be turned off by pressing
SET TEMP CLOCK/TIMER
FA
N ON/OFF
COOL ON/OFF PROGRAM
Office Pro 36
SET
START TIME
END TIME
SET CLOCK
RUN
HRS MIN
87
12
11
9
10
FF button must be pressed.FF
