16
CONNECTING PROJECTOR
CONNECTING TO VIDEO EQUIPMENT
ANALOG RGB
R/Pr G/Y B/Pb H/HV V
CONTROL PORT
DVI
INPUT 1
R/C JACK
USB
RESET
(MONO)
(MONO)
(MONO)
(MONO)
(MONO)
CONTROL PORT
AUDIO
CONTROL PORT
S-VIDEO
VIDEO/Y
C
INPUT 2INPUT 3INPUT 4
AUDIO
AUDIO
AUDIO
SERIAL PORT IN
SERIAL PORT OUT
AUDIO OUT
R
L
R
L
R
L
R
R
L
L
Video Source (example)
Video Cassette Recorder
Video Disc Player
RGB Scart
21-pin Output
Audio Amplifier
Audio Speaker (stereo)
Audio Cable
(Stereo)
S-VIDEO
Output
Audio Input
Cables used for connection
Video Cable (BNC x 1, BNC x 2 or BNC x 3) DVI Cable
HDB 15 pin-Scart 21 pin Cable DVI-VGA Adapter
S-VIDEO Cable Audio Cable (RCA x 2)
( = Cables are not supplied with this projector.)
NOTE :
When connecting cable, power cords of both a
projector and external equipment should be
disconnected from AC outlet. Turn a projector
and peripheral equipment on before computer is
switched on.
Audio Output
Y
Pb/CbPr/Cr
RL
External Audio Equipment
AV AUDIO IN
S-VIDEO
Pr/Cr-Y-Pb/Cb
VIDEO
AUDIO OUT
Component video output equipment.
(such as DVD player or
high-definition TV source.)
Composite
Video Output
Component Video Output
Audio Cable
(Stereo)
Video
Cable
Video
Cable
Separate Y/C
Video Output
YC
Y-C
Terminals of
a Projector
Digital Output
(HDCP compatible)
S-VIDEO
Cable
DVI Cable
DVI-VGA
Adapter
HDB 15 pin-
SCART 21 pin
Cable
DVI
