M1 Installation and Programming Manual
Page 4
OUT3 On LED
J-16 Programmable Outputs
See Note 1
& Note 2
Lighting
Interface Conn.
See Note 5
J4
1 WAY
(PL513/PSC04)
Select PLC Mode
2 WAY
(TW523/PSC05)
JP2
RS232 CONN.
J5
Siren or Voltage
Voice & Siren
Dry Contact Relay
rated 5A @
12 - 28VDC
See Note 2
OUT 1 OUT 3
N/C
COM
N/O
OUT 2
Notes
1. Maximum COMBINED continuous current
drain from terminals +SAUX,+VAUX,+VKP,
OUT2 and J16 is 1.5 Amps. Under alarm the
combined outputs should not exceed 2.5 Amps.
RED
BLACK
WHITE
GREEN
+VAUX
+12VDC Auxiliary
Power (3)
1.25 Amp PTC
protected
Grey
Brown
Red
Green
TELCO
LINE
HOUSE
PHONES
Z1
NEG
Z2
Z3
NEG
Z5
NEG
Z7
Z6
Z4
NEG
Z8
Z9
NEG
Z10
Z11
NEG
Z13
NEG
Z15
Z14
Z12
NEG
Z16
+SAUX
NEG
+VAUX
NEG
+VAUX
NEG
+VAUX
NEG
AC
16.5 V
AC
+VKP
DATA B
DATA A
NEG
OUT 16
OUT 15
OUT 14
OUT 13
OUT 12
OUT 11
OUT 10
OUT 9
OUT 8
OUT 7
+12V
NEG
T1
R1
RING
TIP
Aux Data Bus
See Manual
and Note 5
Serial Port for
Computer/ELKRP
See manual
and Note 5
J3
B
A
-
C
+
Audio Network Interface See Note 5
1
Keypad &
Data Bus
J2 J1
16 Zones expandable to 208
Do Not
Connect to
a Phone
Line!
Not Used -See Note 3
BATTERY
ON
SW1
+
-
12V Battery
7 to 18 Ah
Keypad
Testing of this system should be performed
regulary. Control panel specifications are subject
to change without notice.
Complies with FCC Part 68:
Reg. # US: 5K6AL03BELK-M1 REN: 0.3B
Use Standard Jack: USOC RJ-31X.
Serial Number located below on base.
Complies with part 15 of FCC rules.
See Note 2
+SAUX
+12VDC Switched
Smoke Power
1.1 Amp PTC
protected
NEG
DATA B
+12V
JP3
Jumper to start with
no AC - See Note 4.
Power
Status
Reverse
Bat Leads
UL Listed Transformer,
Class II, 16.5VAC, 45VA
Do not connect to a
switched outlet.
ELK-TRG1640
NORMAL
ZONE 16
JP1
SMOKE
2WIRE
TELCO SEIZED
DIALER ACTIVE
Set JP1 to '2WIRE SMOKE' and use 680 Ohm
EOL resistor, part # ELK-ER680
Use Only Compatible Detectors:
System Sensor: 1151, 2100, 2100T, 2151
GE: 429AT, 521BXT, 521B.
Hochiki America: SLK-835.
Detection Systems: DS250, DS250TH, DS282,
DS282TH, DS282THS, DS282THC.
1
N.C.
N.O.
ZONE
2200
Ohm
EOL
2
N.C.
N.O.
ZONE
2200
Ohm
EOL
3
N.C.
N.O.
ZONE
2200
Ohm
EOL
4
N.C.
N.O.
ZONE
2200
Ohm
EOL
5
N.C.
N.O.
ZONE
2200
Ohm
EOL
6
N.C.
N.O.
ZONE
2200
Ohm
EOL
7
N.C.
N.O.
ZONE
2200
Ohm
EOL
8
N.C.
N.O.
ZONE
2200
Ohm
EOL
9
N.C.
N.O.
ZONE
2200
Ohm
EOL
10
N.C.
N.O.
ZONE
2200
Ohm
EOL
11
N.C.
N.O.
ZONE
2200
Ohm
EOL
12
N.C.
N.O.
ZONE
2200
Ohm
EOL
13
N.C.
N.O.
ZONE
2200
Ohm
EOL
14
N.C.
N.O.
ZONE
2200
Ohm
EOL
15
N.C.
N.O.
ZONE
2200
Ohm
EOL
16
N.C.
N.O.
ZONE
2200
Ohm
EOL
2-Wire Smoke Detector - Zone 16 ONLY
4-Wire Smoke Detector - Any Zone
2200
Ohm
EOL
To Zone Input
U.L. Listed EOL Supervision Relay, ESL #204A
or equiv. Use 2,200 Ohm EOL resistor, part #
ELK-ER2200. Set JP1 to 'Normal'.
N.O. Alarm Contacts
+
-
+
-
+SAUX
To Zone NEG
NEG
DATA A
+
-
+
-
See Note 2
Data Bus Terminating Resistor
See Note 1.
Data Bus
See Note 1
J7
1.25 Amp PTC
protected
112404
ELK
PRODUCTS, INC.
HILDEBRAN, N.C., 28637, USA
1
1
Cross Platform Control
All circuits are power limited except Telco and
Battery leads.
PSC05 or
Equivalent
ELK-M1
Maximum Number = 20 Do not mix models.
StripStrip Wires to 1/4" Length
+
680
Ohm
EOL
-
NEG
Z16
2. OUT 1 is for speakers 4 to 8 Ohms. If using
more than 2 speakers, use series/parallel wiring
to avoid going below a 4 ohm total load.
OUT 2 may be set for speaker OR voltage. It is
supervised against opens. If not used, install
2,2k Ohm resistor across terminals to avoid
Output 2 Trouble condition. In speaker mode
(default), avoid going below a 4 ohm total load.
In voltage mode (switched to ground, 1A Max.)
use UL Listed self-contained siren or bell.
OUT 3 is a NO/NC dry contact relay rated 5A.
OUT 7 through 16 are +12V switched positive
voltage outputs rated at 50mA max.
3. This former earth ground terminal is no longer
used. Do NOT connect this terminal or any neg
terminal to earth ground.
4. If AC fails, low battery disconnect shuts down
the control at 10.2 Volts. To start the control with
a good battery and no AC, short the silver pads
momentarily. Replace Battery every 3-5 years.
Test regularly with ELK-BLT Battery Life Tester.
5. These particular items not evaluated by UL.
O - I - B A +
(Supervised)
