Chapter 6: Programming Information A794 Owner’s Guide
March 199996
Select or Cancel Automatic Status Back (ASB) (continued)
Second Byte (Error information)
Bit Off/On Hex Decimal Status for ASB
0 - - - Undefined
1 - - - Undefined
2 - - - Undefined
3Off
On
00
08
0
8
No knife error.
Knife error occurred.
4 Off 00 0 Not used. Fixed to off.
5Off
On
00
20
0
32
No unrecoverable error.
Unrecoverable error occurred.
6Off
On
00
40
0
64
No recoverable error.
Recoverable Error : Cover open, paper out,
temperature or voltage error is out of range.
7 Off 00 0 Not used. Fixed to off.
Third Byte (Paper Sensor Information)
Bit Off/On Hex Decimal Status for ASB
0Off
On
00
01
0
1
Paper present
Paper low ( if paper low sensor enabled)
1Off
On
00
02
0
2
Paper present
Paper low ( if paper low sensor enabled)
2Off
On
00
04
0
4
Paper present.
Paper exhausted.
3Off
On
00
08
0
8
Paper present.
Paper exhausted.
4 Off 00 0 Not used. Fixed to off.
5 - - - Undefined
6 - - - Undefined
7 Off 00 0 Not used. Fixed to off.
Fourth Byte (Paper Sensor Information)
Bit Off/On Hex Decimal Status for ASB
0 - - - Undefined
1 - - - Undefined
2 - - - Undefined
3 - - - Undefined
4 Off 00 0 Not used. Fixed to off.
5 - - - Undefined
6 - - - Undefined
7 Off 00 0 Not used. Fixed to off.
