11. Check the Tractor Select indicator to see which tractor is
selected:
T If the front tractor arrow light is red, press the LF/FF
Load button to load the paper.
T If the rear tractor arrow light is red, press the
Front/Rear button to switch to the front tractor.
When the printer switches tractors, it also loads
the paper automatically.
The Tractor Select indicator changes to green and the
Paper Out light turns off. The paper is now loaded to the
top-of-form position. If it looks like the printing will start
too high or low on the page, adjust the paper position as
described on page 3-17.
D-2-10-A
d-2-10-b
3
R
Peony Rev.C
A5 size Chapter 3
98/01/07 Pass 4
Paper Handling 3-9
