5
SelecType
5-37
Pens 0 through 6
Selects the thickness of the seven “pens” used to make the
printout.
* Pen2 through Pen6 are available only when GLlike is selected in GLMode Item.
The table below shows the differences between these modes. For
more information on GL/2 commands in LJ4 emulation mode,
see Appendix C.
Item Values
GLMode GLlike, LJ4GL2
Scale Off, A0, A1, A2, A3
Origin Corner, Center
Pen Pen0, Pen1, Pen2, Pen3, Pen4,
Pen5, Pen6
End Butt, Square, Triangular, Round
Join Mitered, Miteredbeveled,
Triangular, Round, Beveled, None
Pen 0 through 6* 0.05 - 5.00 mm in steps of 0.05 mm
Command HP GL/2 mode EPSON GL/2 mode
Orientation Printer setting Landscape only
Plotter unit 1/1016 inch 1/1021 inch
Picture frame Same as LaserJet 4
mode
Depends on the hard-
clip limit
Default position of
P1 and P2
Lower left and lower
right corners,
respectively, of
picture frame
inside of picture frame
Undefined
commands
First character is
ignored
First two characters are
ignored
CS, CA
commands
Not supported Partially supported
