CPU Holder
Bracket for
Peripheral to
Post
Example of multiple
Extender Arms mounted
using 97-096-099
Example of multiple Suspension
Arms mounted using 97-095-099
Example of CPU
Holder mounted
using 97-097-099
Mounting Systems
Mount a second component to the 3" x 3" or 4" x 4" Post Brackets by ordering one of these
Fastener Kits.
Part Description
Number
97-095-099 Fastener Kit, Suspension, Lift or Fixed Arm
97-096-099 Fastener Kit, Extender Arm
97-097-099 Fastener Kit, CPU Holder
Note: When mounting Extender Arm or multiple monitor arms to Command Post, use 4" x 4" Post only.
Second Component
Fastener Kits for
Command Posts
Peripherals require a bracket (unless noted otherwise) for mounting to a Command Post. Order
brackets according to the post size to which you are mounting.
Part Description
Number
60-157-000 Bracket for Peripheral, 2" x 2" Post
60-158-000 Bracket for Peripheral, 3" x 3" Post
60-159-000 Bracket for Peripheral, 4" x 4" Post
Note: See the selection of available peripherals on pages 19–21.
Note: If you plan to mount a monitor arm and peripheral on the same bracket, order Bracket for Arm to Post (previous
page) and Fastener Kit #97-097-099 (above).
Brackets for Mounting
Peripherals to
Command Posts
