15 of 18
888-45-040P-01 rev.H • 10/07
SWING (side-to-side)
PORTRAIT/LANDSCAPE
Display Notebook
C Arm Swing – Side-to-side
If it does not stay in place or move-
ment is stiff, tension needs adjust-
ment. Adjust until motion is equal.
Adjust Arm Swing – Side-to-side
To increase tension
- Turn Clockwise
To decrease tension
- Turn Counterclockwise
