24 MIDI Keyboard
A bank of MIDI keyboard controlled FX - from harmony to resonance, tremolo, harmonics extraction…
2410 Midi Harmony 96 2,2
[K]{PM} Four pitch shifters into a stereo mixer. Can play 4 part harmony when used with midi keyboard. Full ADSR. Mono
in, stereo out.
2411 MIDI Monitor 96 ,
MIDI Note Number Translator and Display. This displays the last MIDI note received in several useful ways: As
MIDI Note Number, Cents (above MIDI note 0), frequency and Period. Use this module when creating presets which
use MIDI note input to control Parameters. Use Cents to control Pitch modules, use frequency to set values for
modulation effects use Period to set values for delay times (useful for resonant delays) In some cases, you may wish to
multiply the values coming from this module in order to get them into a useful range for your purposes. Nothing in,
nothing out.
2412 Midi Pitch Delay 96 4,4
[KS]{D} Makes inharmonic sounds harmonic! Notes controlled from a MIDI keyboard. ADSR controls dynamics. Speed
controls how fast notes change. Fb controls feedback. Quad in, quad out.
2413 Midi Resonance 96 4,4
[KS]{ME} Play a highpass filter from a midi keyboard. 'Depth' controls the resonance. 'Midi' selects the midi channel.
'Speed' adds 'glide' between notes. If you change the 'Mode' to 'Panning' you can control aspects of the panning from
the 'Panning' menu page. Quad in, quad out.
2414 Midi Sine Ring Mod 96 4,4
[KS] Ring mods the input signal with a sine wave controlled from a Midi keyboard. Speed controls how quickly the sine
wave changes freq. Quad in, quad out.
2415 MIDI Tremolo 96 4,4
[KS] Four Tremolo modules. The rate of each one is set by the pitch of the incoming MIDI note(s). This preset requires
incoming MIDI notes. The tremolo rate will be the same as the fundamentalfrequency of the incoming MIDI note. Use
the TremRate display to view the rate of the tremolos. If you find that the incoming MIDI notes are setting your tremolo
rates too fast, use the freqMult parameter to scale the LFO rates up or down to your liking. High freqMult settings and
high MIDI notes yield a distorted LoFi sound while lower notes and lower settings give more typical Tremolo effects.
Use various MIDIintervals to to create musically interesting tremolo effects: Playing an octave yields two Tremolos with
a 2:1 ratio between their rates. Perfect fourths yield a 3:4 ratio. Create your own LFO shapes for each Tremolo using
the Tremolo parameters. Change how MIDI notes are assigned to the Tremolo speeds using the MIDI Mode parameter.
Use output panners to set the quad panning of the 4 tremolos. Use the Input parameter to switch from stereo to quad
input. Quad in, quad out.
2416 MidiHarmonixExtract 48 2,4
[KS] Extracts the harmonic content of a note played on a MIDI keyboard from the input signal. Speed controls how
fast the 'extracting' note changes. Mono in, quad out.
2417 MidiWaveformImpose 96 2,4
[KS]{E} Sets the center freqs of 24 bandpass filters to the first 24 harmonics of a note played on a MIDI keyboard. Midi
parameter sets channel. Speed controls how fast notes change. Increase PeakQ to highten 'note' effect. Mono in, quad
out.
2418 QuadOffsetTrem 96 4,4
[KS]{D} Four tremolo modules. All use the same LFO. LFO Rate can be set between 0 and 20KHz! Use lower settings for
standard trem effects, higher rates for lo-fi distorted sound. Change the relative phase of the 4 trems using the
TimeOffset control. This will give a wider effect. Create your own LFO shape using the Custom Waveform designer. On
the In/Out page you can set the output panning of each of the Tremolos and select from either Stereo or Quad input.
Quad in, quad out.
